| VALVES & WELL HEADS | SIZE | THICKNESS | CLAD / WELDOVERLAY THICKNESS |
|---|---|---|---|
| Well Head , Valve Body & Bonnet And X‐mass Tree | As per customer requirement | As per customer requirement | 1.5 mm & above |
| PIPES | DIAMETER | THICKNESS | CLAD / WELDOVERLAY THICKNESS |
| Welded pipes | 2" NB to 42" NB | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| Seamless pipes | 2" NB to 42" NB | Minimum 7mm & above | |
| FITTINGS | SIZE | THICKNESS | WELDOVERLAY THICKNESS |
| Elbows | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| Reducers | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| Tees | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| Weldolets | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| Sockolets | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm |
| FITTINGS | SIZE | THICKNESS | WELDOVERLAY THICKNESS |
| WNRF, BLRF, WNRTJ | 2" & above | Minimum 7mm & above | 1.5 mm to 4.5 mm (or as reqd.) |
| VESSELS & HEADERS | DIAMETER | THICKNESS | WELDOVERLAY THICKNESS |
| VESSELS | 600mm to 500mm & up to 20mtr. Long | Minimum 7mm & above | 1.5 mm to 4.5 mm |
